Technical Specifications


Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

206 kW (280 hp) at 7600 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4325 mm

Width

1725 mm

Height

1245 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

  1393 mm

Kerb weight

1100 kg


Performance


Top speed

258 km/h


Total

448
 Previous page
 Next page
Up

Ferrari 275 GTB s/n 07953

LHD
6 (3) carb
alloy

Ferrari 275 GTB s/n 07955
LHD
6 (3) carb
steel

Ferrari 330 GT 2+2 S2 s/n 7755GT

Ferrari 275 GTB s/n 07959

LHD
6 carb
alloy (steel)

Ferrari 275 GTB/6C, s/n 07959

Ferrari 275 GTB s/n 07961

LHD
6 (3) carb
alloy

Ferrari 275 GTS s/n 06889

Ferrari 275 GTB s/n 07969

LHD
6 carb
alloy

Ferrari 275 GTB s/n 07971

LHD
(3) 6 carb
alloy (steel)

Ferrari 275 GTB s/n 07981

LHD
3 carb
steel

Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 07983

LHD
6 carb
alloy

Ferrari 275 GTB s/n 07991

LHD
3 carb
alloy

Ferrari 275 GTB Longnose s/n 07991

Ferrari 275 GTB s/n 07993

LHD
6 carb
alloy (steel)

Ferrari 275 GTB s/n 07995

LHD
6 (3) carb
alloy

Ferrari 275 GTB/6C, s/n 07995

Ferrari 275 GTB s/n 08011

LHD
6 carb
alloy (steel)

Ferrari 275 GTB s/n 08013

LHD
3 carb
allooy (steel)

Ferrari 275 GTB s/n 08017

LHD
3 carb
alloy (steel)


Ferrari 275 GTB s/n 08021

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 07821

Ferrari 275 GTB s/n 08027

RHD
6 carb
steel

Ferrari 275 GTB s/n 08029

LHD
6 carb
alloy (steel)


Ferrari 330 GT 2+2 Series II s/n 7029GT

Ferrari 275 GTB s/n 08031

RHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08033

LHD
3 carb
steel

Ferrari 275 GTB s/n 08035

LHD
6 carb
alloy (steel)


Ferrari 275 GTB s/n 08037

LHD
3 carb
steel


Ferrari 275 GTB s/n 08039

LHD
3 carb
steel

Ferrari 275 GTS s/n 07939

Ferrari 275 GTB s/n 08041

LHD
3 carb
steel

Ferrari 275 GTS s/n 07841

Ferrari 275 GTB s/n 08043

LHD
3 carb
steel

Ferrari 330 GT 2+2 SII s/n 7843GT

Ferrari 275 GTB s/n 08045

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08047

RHD
6 carb
steel


275 GTB/2 Longnose s/n 08047

Ferrari 275 GTB s/n 08049

LHD
3 carb
alloy (steel)

275 GTS s/n 07649

Ferrari 275 GTB s/n 08051

LHD
3 (6) carb
alloy

Ferrari 275 GTB s/n 08051

Ferrari 275 GTB s/n 08053

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08055

RHD
6 carb
steel

Ferrari 275 GTB s/n 08057

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08059

LHD
3 carb
alloy


275 GTB longnose alloy, s/n 08059

Ferrari 275 GTB s/n 08061

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08063

LHD
3 carb
steel

Ferrari 330 GT 2+2 s/n 7963 - "Shooting Break" by Vignale

Ferrari 275 GTB s/n 08065

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08067

LHD
6 carb
alloy

Ferrari 275 GTB s/n 08069

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08071

RHD
6 (3) carb
alloy (steel)

Ferrari 275 GTB s/n 08077

RHD
6 carb
alloy

Ferrari 275 GTB s/n 08079

LHD
6 (3) carb
alloy (steel)

Ferrari 275 GTB s/n 08081

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 08085

LHD
6 (3) carb
steel

Ferrari 275 GTS s/n 07885

Ferrari 275 GTB s/n 08087

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 07887

Ferrari 275 GTB s/n 08089

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08091

LHD
6 carb
steel

275 GTB/6C Longnose s/n 08091

Ferrari 275 GTB s/n 08111

LHD
3 carb
alloy

Ferrari 275 GTB short nose front section s/n 7511

Ferrari 275 GTB s/n 08113

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08117

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08119

LHD
3 carb
steel

500 Superfast s/n 8019SF

Ferrari 275 GTB s/n 08121

LHD
6 carb
alloy

Ferrari 275 GTB s/n 07821
