Technical Specifications


Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

206 kW (280 hp) at 7600 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4325 mm

Width

1725 mm

Height

1245 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

  1393 mm

Kerb weight

1100 kg


Performance


Top speed

258 km/h


Total

448
 Previous page
 Next page
Up

Ferrari 275 GTB s/n 08123

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08125

LHD
3 carb
alloy

Ferrari 330 GT s/n 8025GT

Ferrari 275 GTB s/n 08135

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08137

LHD
6 (3) carb
alloy

Ferrari 275 GTB s/n 08143

LHD
3 (6) carb
alloy

Ferrari 275 GTB s/n 08145

LHD
3 (6) carb
alloy

Ferrari 275 GTB alloy longnose, s/n 08145

Ferrari 275 GTB s/n 08151

LHD
3 carb
alloy (steel)


275 GTB alloy longnose, s/n 08151

Ferrari 275 GTB s/n 08155

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08155

Ferrari 275 GTB s/n 08157

LHD
6 (3) carb
alloy

Ferrari 275 GTB s/n 08159

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08159

Ferrari 275 GTB s/n 08163

LHD
3 carb
steel

Ferrari 330 GT 2+2 s/n 7963 - "Shooting Break" by Vignale

Ferrari 275 GTB s/n 08179

RHD
6 carb
alloy

275 GTB/6C Alloy Berlinetta RHD longnose red/black s/n 8179 - Lot 132

Ferrari 275 GTB s/n 08181

RHD
6 carb
steel

Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 08187

LHD
3 carb
steel

Ferrari 275 GTB s/n 07887

Ferrari 275 GTB s/n 08191

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08193

LHD
3 carb
steel

Ferrari 275 GTB s/n 08199

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08209

LHD
3 carb
steel

Ferrari 275 GTB s/n 08213

LHD
3 carb
alloy (steel)

250 GTE "Drogo" Conversion red/red s/n 3213GT/3881

Ferrari 275 GTB s/n 08219

RHD
3 (6) carb
alloy (steel)

275 GTB Longnose s/n 08219

Ferrari 275 GTB s/n 08221

RHD
6 carb
alloy

Ferrari 275 GTB s/n 08225

LHD
3 (6) carb
alloy

Ferrari 275 GTB s/n 08229

LHD
6 carb
steel

rebodied in alloy by Fantuzzi, outside filler and roll cage added

Ferrari 275 GTB s/n 08233

LHD
6 carb
alloy (steel)

modified with outside filler

Ferrari 275 GTB s/n 08241

RHD
3 (6) carb
alloy

Ferrari 275 GTS s/n 07841

Ferrari 275 GTB s/n 08247

LHD
3 carb
alloy (steel)

275 GTB/2 Longnose s/n 08047

Ferrari 275 GTB s/n 08249

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08255

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08259

LHD
6 carb
alloy

275 GTB/2 longnose s/n 08259

Ferrari 275 GTB s/n 08263

LHD
6 (3) carb
alloy (steel)

Ferrari 330 GT 2+2 s/n 7963 - "Shooting Break" by Vignale

Ferrari 275 GTB s/n 08277

RHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 08297

LHD
6 carb
steel

Ferrari 275 GTB s/n 08305

LHD
3 carb
steel

Ferrari 275 GTS s/n 08005

Ferrari 275 GTB s/n 08311

LHD
6 (3) carb
alloy

Ferrari 275 GTB short nose front section s/n 7511

Ferrari 275 GTB s/n 08317

LHD
3 carb
steel

Ferrari 275 GTB s/n 08323

LHD
6 carb
steel

Ferrari 275 GTB s/n 08327

LHD
6 carb
steel

Ferrari 275 GTB s/n 08337

LHD
6 carb
steel

Ferrari 275 GTB s/n 08887 in car 08337

Ferrari 275 GTB s/n 08341

RHD
6 (3) carb
steel

Ferrari 275 GTS s/n 07841

Ferrari 275 GTB s/n 08343

LHD
6 (3) carb
alloy

Ferrari 275 GTB s/n 08349

LHD
3 carb
steel

Ferrari 275 GTB s/n 08355

LHD
3 carb
steel (alloy)

Ferrari 275 GTB s/n 08359

LHD
3 carb
steel

275 GTB longnose, s/n 08359

Ferrari 275 GTB s/n 08365

LHD
3 carb
steel

Nürburgring 1000 km 1966: The 250 LM s/n 8165 was the last of a series of 32 cars. At the Nürburgring, it was driven by Mairesse/ Müller to a 9th place. It was later sold to David Piper

Ferrari 275 GTB s/n 08371

LHD
3 carb
steel

sun roof added


Ferrari 275 GTB s/n 08371

Ferrari 275 GTB s/n 08377

RHD
3 carb
steel

Ferrari 275 GTB s/n 08381

LHD
6 carb
steel


Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 08385

LHD
3 carb
steel

Ferrari 275 GTS s/n 07885

Ferrari 275 GTB s/n 08389

LHD
3 carb
steel

Ferrari 275 GTB s/n 08391

LHD
3 carb
steel
