Technical Specifications


Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

206 kW (280 hp) at 7600 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4325 mm

Width

1725 mm

Height

1245 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

  1393 mm

Kerb weight

1100 kg


Performance


Top speed

258 km/h


Total

448
 Previous page
 Next page
Up

Ferrari 275 GTB s/n 07633

LHD
3 carb
steel

Ferrari 275 GTB s/n 07637

LHD
3 carb
alloy

Ferrari 275 GTB s/n 07645

LHD
3 carb
steel

Ferrari 275 GTB s/n 07651
LHD
3 carb
steel

long nose conversion

275 GTB longnose, s/n 07651

Ferrari 275 GTB s/n 07657

LHD
3 carb
steel


Ferrari 275 GTS s/n 07457 - Lot 106

Ferrari 275 GTB s/n 07661

LHD
3 carb
steel



275 GTB/2 Longnose Spyder Conversion s/n 07061

Ferrari 275 GTB s/n 07665

LHD
3 carb
steel

Ferrari 275 GTB s/n 07665

Ferrari 275 GTB s/n 07675

LHD
3 carb
steel

Ferrari 275 GTB s/n 07677

RHD
6 carb
steel

Ferrari 275 GTB s/n 07683

LHD
3 carb
steel

Ferrari 275 GTS Pininfarina Spyder s/n 07383

Ferrari 275 GTB s/n 07689

LHD
steel



Ferrari 275 GTB s/n 07699

LHD
3 carb
steel

Ferrari 275 GTB s/n 07699

Ferrari 275 GTB s/n 07707

Long nose Prototipo

LHD
3 carb
steel

Ferrari 275 GTB/C, s/n 07407

Ferrari 275 GTB s/n 07711

Long nose Prototipo

LHD
3 carb
steel

Ferrari 275 GTB short nose front section s/n 7511

Ferrari 275 GTB s/n 07715

RHD
6 carb
steel

Ferrari 275 GTB s/n 07723

LHD
3 carb
steel


Ferrari 275 GTB s/n 07733

RHD
3 (6) carb
steel

Ferrari 275 GTB s/n 07735

LHD
3 (6) carb
steel

Ferrari 275 GTS s/n 07235

Ferrari 275 GTB s/n 07739

LHD
3 carb
steel

Ferrari 275 GTB s/n 07743

LHD
3 carb
steel

Ferrari 275 GTB s/n 07747

LHD
3 carb
steel

Ferrari 275 GTB s/n 07751

LHD
3 carb
steel

Ferrari 275 GTB s/n 07765

LHD
3 carb
steel

Ferrari 275 GTB, s/n 07765

Ferrari 275 GTB s/n 07769

LHD
3 carb
steel

Ferrari 275 GTB s/n 07269

Ferrari 275 GTB s/n 07773

LHD
3 carb
steel

Ferrari 275 GTB s/n 07781

LHD
3 carb
steel

Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 07785

LHD
3 carb
steel

Ferrari 275 GTB s/n 07785

Ferrari 275 GTB s/n 07789

RHD
3 carb
steel

Ferrari 275 GTB s/n 07793

LHD
6 carb
steel

275 GTS s/n 7493

Ferrari 275 GTB s/n 07797

RHD
6 carb
steel

long nose conversion


Ferrari 275 GTB s/n 07803

LHD
3 carb
steel

Ferrari 275 GTB s/n 07603 Spyder conversion

Ferrari 275 GTB s/n 07807

LHD
3 carb
steel

Ferrari 275 GTB/C, s/n 07407

Ferrari 275 GTB s/n 07809

LHD
3 carb
alloy

long nose

Ferrari 250 GT/L s/n 5045GT

Ferrari 275 GTB s/n 07819

LHD
3 carb
steel

long nose conversion

Ferrari 275 GTB s/n 07821

LHD
3 carb
steel

Ferrari 275 GTB s/n 07821

Ferrari 275 GTB s/n 07827

LHD
3 carb
steel

Ferrari 275 GTB s/n 07855

LHD
3 carb
steel

Ferrari 330 GT 2+2 S2 s/n 7755GT

Ferrari 275 GTB s/n 07869

LHD
3 carb
steel

275 GTB, s/n 07869

Ferrari 275 GTB s/n 07871

LHD
6 carb
steel

Ferrari 275 GTB s/n 07873

LHD
3 carb
steel

long nose

275 GTB s/n 07873

Ferrari 275 GTB s/n 07881

LHD
3 carb
steel

last short nose

Ferrari 275 GTB s/n 7781 - Lot 107a

Ferrari 275 GTB s/n 07887

LHD
3 carb
alloy (steel)

Ferrari 275 GTB s/n 07887

Ferrari 275 GTB s/n 07893

LHD
3 carb
steel

275 GTS s/n 7493

Ferrari 275 GTB s/n 07899

LHD
3 carb
steel

Ferrari 275 GTB s/n 07905

LHD
3 carb
steel

Ferrari 275 GTB s/n 07911

LHD
3 carb
steel

Ferrari 275 GTB short nose front section s/n 7511

Ferrari 275 GTB s/n 07923

LHD
6 (3) carb
steel

Ferrari 275 GTB s/n 07927

LHD
3 carb
alloy

Ferrari 275 GTB s/n 07931

LHD
6 carb
steel

rebodied Comp. style

Ferrari 275 GTB s/n 07933

LHD
6 carb
alloy
