Technical Specifications

Engine

Type Construction Number

500

Designer

Lampredi

Layout

4 Inline

Engine

Front longitudinal in-line 4-cylinders, light alloy cylinder

block and head

Timing gear

2 valves per cylinder, twin overhead camshafts per

cylinder bank

Drive Gears

Cam Followers Roller Tappet

Valve Design

Inclined

Valves Springs

Hairpin

No. of Spark Plugs/Cylinder

2

Ignition

2 Distributors

No. of Carburetors

2

Type of Carburetors

40 DCO/A3

Bore and stroke

90 x 78 mm

Unitary and total displacement

496.21/1,984.85 cc

Compression ratio

8.5:1 / 8,75:1

Maximum power

180 bhp at 7,000 rpm


Drive Train


Clutch Double

dry twin-plate clutch

Transmission - No. of Gears

4-Speed & reverse

Transmission - Type

All synchro

Transmission - Location

With engine, , ZF limited-slip differential

Axle Ratio

3.77, 4.00, 4.25, 4.57:1


Chassis

Chassis

Welded, elliptical section steel tubes

Tube Frame

Ladder Type

Front suspension

Independent, double wishbones,

coil springs or anti-roll bar

Rear suspension

Live axle, coil springs

Shocks

Houdaille

Brakes

Drum

Wheelbase, front and rear track

2,250/1,380/1,500 mm

Wheels


Front

Borrani

Rear

Borrani

Kerb weight

680 kg

Front tyres

5.50-16

Rear tyres

6.00-16

Fuel tank

120 litres


General

Body Designer

Scaglietti

Body Builder

Scaglietti

Lenght

Overall

  155.0

Width

  64.5

Height

38.0



Total

16

Ferrari 500 TR Scaglietti Spyder s/n 0600MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0600MDTR


Ferrari 500 TR Scaglietti Spyder s/n 0608MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0610MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0610MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0614MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0618MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0620MDTR

1956  Ferrari 500 TR Scaglietti Spider, s/n 0620MDTR  [Knobloch / Gross (AUT)]

Ferrari 500 TR Scaglietti Spider s/n 0622MDTR

Ferrari 500 TR Scaglietti Spider s/n 0622MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0624MDTR

destroyed

Ferrari 625 TR Scaglietti Spyder s/n 0624MDTR

Ferrari 500 TR Scaglietti  Spyder s/n 0634MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0636MDTR

500 TR Scaglietti Spyder s/n 0636MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0638MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0640MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0648MDTR

Ferrari 250 MM Vignale Spyder s/n 0348MM

Ferrari 500 TR Scaglietti Spyder s/n 0650MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0652MDTR

Ferrari 500 TR Spider Scaglietti, s/n 0652MDTR

Ferrari 500 TR Scaglietti Spyder s/n 0654MDTR

Ferrari 500 TR Spyder Scaglietti s/n 0654MDTR
