Technical Specifications



Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

191 kW (260 hp) at 7000 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4350 mm

Width

1675 mm

Height

1250 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

1393 mm

Kerb weight

1100 kg


Performance


Top speed

242 km/h


Total

200



 Previous page
 Next page
Up

Ferrari 275 GTS s/n 07833

Ferrari 330 GTS s/n 07835

Prototipo

Ferrari 275 GTS s/n 07235

Ferrari 275 GTS s/n 07839

Ferrari 275 GTS s/n 07841

Ferrari 275 GTS s/n 07841

Ferrari 275 GTS s/n 07845

275 GTS s/n 07845

Ferrari 275 GTS s/n 07847

Ferrari 275 GTS s/n 07853

Ferrari 275 GTS s/n 07861

Ferrari 275 GTS s/n 06889

Ferrari 275 GTS s/n 07865

Ferrari 275 GTB, s/n 07765

Ferrari 275 GTS s/n 07867

engine 07867 installed ...
uses chassis number 07861 ..

most likely it is 07867

Ferrari 275 GTS s/n 07885

Ferrari 275 GTS s/n 07885

Ferrari 275 GTS s/n 07891

275 GTS s/n 7791

Ferrari 275 GTS s/n 07897


Ferrari 275 GTS s/n 07903

Ferrari 275 GTS s/n 07907

Ferrari 275 GTB/C, s/n 07407

Ferrari 275 GTS s/n 07913

Ferrari 275 GTS s/n 07915

Ferrari 275 GTS s/n 07921

Ferrari 275 GTB s/n 07821

Ferrari 275 GTS s/n 07929

Ferrari 330 GT 2+2 Series II s/n 7029GT

Ferrari 275 GTS s/n 07935

275 GTS s/n 07935

Ferrari 275 GTS s/n 07937

Ferrari 275 GTS s/n 07939

Ferrari 275 GTS s/n 07939

Ferrari 275 GTS s/n 07945

Ferrari 275 GTS s/n 07957

Ferrari 275 GTS s/n 07957

Ferrari 275 GTS s/n 07965

Ferrari 275 GTS s/n 07967

Ferrari 275 GTS s/n 07977

Ferrari 275 GTS s/n 07985

Ferrari 275 GTS s/n 07885

Ferrari 275 GTS s/n 07987

Ferrari 275 GTB s/n 07887

Ferrari 275 GTS s/n 07989

Ferrari 275 GTS s/n 07997

Ferrari 275 GTS s/n 07999

Ferrari 275 GTS s/n 08001

Ferrari 275 GTS s/n 7701 GT



Ferrari 275 GTS s/n 08003

Ferrari 275 GTS s/n 08005

Ferrari 275 GTS s/n 08005

Ferrari 275 GTS s/n 08007

Part of FOC Parking Area& 275 GTS s/n 08007

Ferrari 275 GTS s/n 08009

Ferrari 275 GTS s/n 08015

Ferrari 275 GTS s/n 08287

Ferrari 275 GTB s/n 07887


Ferrari 275 GTS s/n 08303

Ferrari 275 GTS s/n 08313

Ferrari 275 GTS s/n 08335

Ferrari 275 GTS s/n 08353

Ferrari 275 GTS s/n 08353

Ferrari 275 GTS s/n 08369

Ferrari 275 GTS s/n 08375

burned parted out

Ferrari 275 GTS s/n 08397

Ferrari 275 GTS s/n 08621

Ferrari 275 GTS s/n 08631

275 GTS s/n 08631

Ferrari 275 GTS s/n 08653

last built

Destroyed

Ferrari 275 GTS s/n 08353

Ferrari 275 GTS s/n 07825
