Technical Specifications


Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

206 kW (280 hp) at 7600 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4325 mm

Width

1725 mm

Height

1245 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

  1393 mm

Kerb weight

1100 kg


Performance


Top speed

258 km/h


Total

448
 Previous page
 Next page
Up

Ferrari 275 GTB s/n 5161GT

Prototype

330 America s/n 5061GT


Ferrari 275 GTB s/n 06003

LHD
alloy

.. - engine installed in 07927 (275 GTB)

Ferrari 250 LM s/n 5903

Ferrari 275 GTB s/n 06357

LHD
3 carb
steel


Ferrari 275 GTB Speciale s/n 06437

6 carb

275 GTB Speciale s/n 06437

Ferrari 275 GTB s/n 06449

LHD
3 carb
steel


Ferrari 275 GTB s/n 06457

LHD
3 carb
steel

Ferrari 275 GTB s/n 06471

LHD
3 carb
steel


Ferrari 330 GT 2+2 series I, s/n 6271

Ferrari 275 GTB s/n 06489

LHD
3 carb
steel


Ferrari 275 GTB s/n 06505

LHD
3 carb
steel


Ferrari 275 GTB s/n 06507

LHD
3 carb
steel

raced

Ferrari 275 GTB, s/n 06507, Philippe Lancksweert (B)

Ferrari 275 GTB s/n 06517

LHD
3 carb
steel


Ferrari 275 GTB s/n 06521

RHD
6 carb
Steel

Ferrari 275 GTB s/n 06527

RHD
3 carb
steel


Ferrari 275 GTB s/n 6527

Ferrari 275 GTB s/n 06529

LHD
6 carb
steel


250 GT/L, s/n 5729GT

Ferrari 275 GTB s/n 06543

LHD
3(6) carb
steel

Ferrari 500 Superfast, s/n 6043SF

Ferrari 275 GTB s/n 06557

LHD
6 carb
steel


Ferrari 275 GTB s/n 06563

LHD
3 carb
steel


Ferrari 275 GTB s/n 06569

LHD
3 carb
steel


330 GT 2+2 Series I in pale yellow

Ferrari 275 GTB s/n 06575

LHD
3 carb
steel


Ferrari 250 LM, s/n 5975

Ferrari 275 GTB s/n 06585

LHD
3 carb
steel


Ferrari 275 GTB/2 Longnose Conversion s/n 06585

Ferrari 275 GTB s/n 06587

LHD
3 carb
steel


Ferrari 275 GTB s/n 06589

LHD
3 carb
steel


Ferrari 275 GTB  s/n 06599

RHD
6 carb
steel


Ferrari 275 GTB s/n 06601

LHD
3 carb
steel




Ferrari 275 GTB s/n 06603

LHD
6 carb
steel


Ferrari 275 GTB s/n 06609

LHD
3 carb
steel


Ferrari 275 GTB s/n 06611

LHD
3 carb
steel


Ferrari 275 GTB s/n 06617

LHD
3 carb
steel


Ferrari 275 GTB s/n 06617

Ferrari 275 GTB s/n 06619

LHD
3 carb
steel


Ferrari 275 GTB s/n 06621

LHD
3 carb
steel


Ferrari 275 GTB s/n 06629

LHD
6 carb
steel


250 GT/L, s/n 5729GT

Ferrari 275 GTB s/n 06631

LHD
3 carb
steel


Ferrari 275 GTB s/n 06639

LHD
3 (6) carb
steel


Ferrari 275 GTB s/n 06643

LHD
3 carb
steel


Ferrari 275 GTB s/n 06645

LHD
3 carb
steel


Ferrari 275 GTB s/n 06651

LHD
3 carb
steel


Ferrari 275 GTB s/n 06653

LHD
3 carb
steel


Ferrari 275 GTB s/n 06655

LHD
3 carb
steel


Ferrari 275 GTB longnose s/n 06655

Ferrari 275 GTB s/n 06663

LHD
3 carb
steel


Ferrari 275 GTB s/n 06665

LHD
3 (6) carb
steel


Ferrari 275 GTB s/n 06669

LHD
6 carb
steel


330 GT 2+2 Series I in pale yellow

Ferrari 275 GTB s/n 06671

LHD
3 carb
steel


Ferrari 330 GT 2+2 series I, s/n 6271

Ferrari 275 GTB s/n 06677

RHD
6 carb
steel


Ferrari 275 GTB s/n 06681

LHD
3 carb
steel


Ferrari 275 GTB s/n 06681

Ferrari 275 GTB s/n 06683

RHD
6 carb
steel


275 GTB s/n 6683

Ferrari 275 GTB s/n 06691

LHD
3 carb
steel


Ferrari 275 GTB shortnose, s/n 06691

Ferrari 275 GTB s/n 06693

LHD
3 carb
steel


Ferrari 275 GTB s/n 06695

LHD
3 carb
steel



Ferrari 275 GTB s/n 06703

LHD
3 carb
steel


275 GTB/2 Shortnose s/n 06703

Ferrari 275 GTB s/n 06577

LHD
6 carb
steel
