Technical Specifications


Engine

Type

rear, longitudinal 60° V12

Bore/stroke

73 x 58.8 mm

Unitary displacement

246.10 cc

Total displacement

2953.21 cc

Compression ratio

9.5 : 1

Maximum power

228 kW (310 hp) at 7500 rpm

Power per litre

105 hp/l

Valve actuation

single overhead camshaft per bank,

two valves per cylinder

Fuel feed

six Weber 38 DCN carburettors

Ignition

single spark plug per cylinder, two coils

Lubrication

dry sump

Clutch

multi-plate


Chassis

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs, telescopic shock absorbers, anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs, telescopic shock absorbers, anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

rack-and-pinion

Fuel tank

capacity 130 litres

Front tyres

5.50 x 15

Rear tyres

7.00 x 15


Bodywork

Type

two-seater spider

Length

4015 mm

Width

1670 mm

Height

1080 mm

Wheelbase

2400 mm

Front track

1350 mm

Rear track

1340 mm

Weight

760 kg (dry)


Performance


Top speed

290 km/h



Total

4


 Previous page
 Next page
Up

Ferrari 250 P Fantuzzi Spyder s/n 0810

Le Mans 24h 1963: While their team-mates Bandini and Scarfiotti won, finished Mike Parkes and Umberto Maglioli 3rd with the 330 P s/n 0810

Ferrari 250 P Fantuzzi Spyder s/n 0812

rebodied at Michelotti
rebodied to former body style

Le Mans 24h 1963: John Surtees and Willy Mairesse had won the race on the Nürburgring four weeks earlier, but were luckless at Le Mans. The Ferrari 250P s/n 0812 caught fire after a refueling stop while it was running in front and burned out completely

Ferrari 250 P Fantuzzi Spyder s/n 0814

Le Mans 24h 1963: The victory of Lorenzo Bandini and Ludovico Scarfiotti with the 330P s/n 0814 was Ferrari’s forth successive win in the French classic race

Ferrari 275 P Fantuzzi  Spyder s/n 0816

275 P Fantuzzi  Spyder s/n 0816
