Technical Specifications


Engine

Type

128F and 128E/63

Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder, single overhead camshaft per

cylinder bank

Bore and stroke

73 x 58.8 mm

Unitary and total displacement

246.10/2,953.21 cc

Compression ratio

8.8:1

Maximum power

240 bhp at 7,000 rpm

Fuel feed

3 twin choke Weber 40 DCL6 carbs

Ignition

single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

4-speed gearbox + overdrive + reverse,

conventional differential


Chassis

Chassis type

508E

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,600 / 1,354 / 1,394 mm

Kerb weight

1,280 kg

Fuel tank

100 litres

Top Speed

230km/h


Total

302
 Previous page
 Next page
Up

Ferrari 250 GTE s/n 3235GT

engine installed 5519GT (330 GT 2+2)

Ferrari 250 GTE s/n 3237GT

.. - rebodied as 250 GT SWB Replica

Ferrari 250 GTE s/n 3241GT

87 - rebodied as 250 GTO Series I

Ferrari 250 GTE s/n 3243GT

Ferrari 250 GTE s/n 3247GT

Ferrari 250 GTE s/n 3249GT

Ferrari 250 GT SWB Berlinetta s/n 2649GT

Ferrari 250 GTE s/n 3251GT

06 - rebodied as 250 GT SWB Replica

Ferrari 250 GTE s/n 3253GT

Ferrari 250 GTE s/n 3153GT

Ferrari 250 GTE s/n 3255GT

Ferrari 250 GTE s/n 3257GT

.. - engine installed in 3809GT (250 GTO)

Ferrari 250 GTE s/n 2357GT

Ferrari 250 GTE s/n 3259GT

Ferrari 250 GTE s/n 3261GT

.. - engine installed from 2205GT

Ferrari 250 GTE s/n 3261GT

Ferrari 250 GTE s/n 3263GT

.. - rebodied as 250 GTO Series I

250 GT California Spider SWB s/n 3163GT

Ferrari 250 GTE s/n 3265GT

Ferrari 250 GTE s/n 3267GT

.. - rebodied as 250 speciale one-of-a-kind

250 GTE s/n 3167GT

Ferrari 250 GTE s/n 3271GT

Ferrari 250 GTE s/n 3273GT

.. - rebodied as 250 GT SWB

Ferrari 250 GT SWB Berlinetta s/n 3073GT

Ferrari 250 GTE s/n 3275GT

Ferrari 250 GT SWB Berlinetta s/n 3175GT

Ferrari 250 GTE s/n 3277GT

Ferrari 250 GTE s/n 3279GT

Ferrari 250 GTE s/n 3283GT

Ferrari 250 GTE s/n 3285GT

Ferrari 250 GT SWB California Spyder s/n 3185GT

Ferrari 250 GTE s/n 3289GT

Ferrari 250 GTE s/n 3291GT

Ferrari 250 GTE s/n 3295GT

Ferrari 250 GT SWB California Spyder s/n 3195GT

Ferrari 250 GTE s/n 3297GT

.. - parted out ?

Ferrari 400 SA Aerodinamico Coupe s/n 3097SA/4031SA

Ferrari 250 GTE s/n 3299GT

Ferrari 250 GT SWB California Spider s/n 3099GT


Ferrari 250 GTE s/n 3303GT

250 GTO 64 replica s/n 3103GT

Ferrari 250 GTE s/n 3305GT

Being parted out

Ferrari 250 GTE s/n 3307GT

250 GTE 2+2, #3207 GT

Ferrari 250 GTE s/n 3313GT

250 GTE “Drogo” Conversion red/red s/n 3213GT/3881 - Lot 122

Ferrari 250 GTE s/n 3317GT

Ferrari 250 GTE s/n 3319GT

Ferrari 250 GTE s/n 3219GT

Ferrari 250 GTE s/n 3321GT

.. - rebodied as 250 LWB cal Spyder (fiberglass)

Ferrari 400 Superamerica s/n 3221SA

Ferrari 250 GTE s/n 3323GT

Ferrari 250 GTE s/n 3325GT

Ferrari 250 GTE s/n 3329GT

Ferrari 250 GT SWB Berlinetta s/n 2729GT

Ferrari 250 GTE s/n 3333GT

Ferrari 250 GTE s/n 3335GT

Ferrari 250 GTE s/n 3339GT

Ferrari 250 GTE s/n 3341GT

Ferrari 250 GTE s/n 3343GT

rebodied GTO style

engine installed from 4703GT (250 GTE 2+2)

250.GTE.3343GT.001

Ferrari 250 GTE s/n 3347GT

Ferrari 250 GTE s/n 3349GT

Ferrari 250 GT SWB Berlinetta s/n 2649GT

Ferrari 250 GTE s/n 3351GT

Ferrari 250 GTE s/n 3353GT

Ferrari 250 GTE s/n 3153GT

Ferrari 250 GTE s/n 3355GT

Ferrari 250 GTE s/n 3357GT

Ferrari 250 GTE s/n 2357GT

Ferrari 250 GTE s/n 3363GT

250 GTE 2+2 (no engine+gearbox) s/n 3363GT - Lot 138

Ferrari 250 GTE s/n 3365GT
