Technical Specifications |
Engine |
Front longitudinal 60° V12, |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| single overhead camshaft per cylinder bank | |
Bore and stroke |
77 x 71.8 mm |
Unitary and total displacement |
330.62/3,967.44 cc |
Compression ratio |
8.8:1 |
Maximum power |
390 bhp at 7,500 rpm |
Transmission |
Dry, multi-plate clutch, |
| 4-speed gearbox + reverse, conventional differential | |
Chassis |
Elliptical section steel tubes |
Front suspension |
Independent, double wishbones, coil springs |
Rear suspension |
Live axle, semi-elliptic leaf springs |
Wheelbase |
2,420 |
front and rear track |
-/- mm |
Kerb weight |
950 kg (dry) |
Fuel tank |
140 litres |
|
|
