Technical Specifications

Engine

Type

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder,

single overhead camshaft per cylinder bank

Bore and stroke

88 x 68 mm

Unitary and total displacement

413.46 cc / 4962.96 cc

Compression ratio

8.5:1

Maximum power

340 bhp at 6,000 rpm

Transmission

Multi-plate clutch, 4 speed-gearbox + reverse,

conventional differential

Chassis

Elliptical section steel tubes

Front suspension

Independent, double wishbones,

transverse lower leaf spring

Rear suspension

Live axle, longitudinal leaf springs

Wheelbase, front and rear track

2,800/1,325/1,320 mm

Kerb weight

1,150 kg

Front tyres

7.10-15

Fuel tank

140 litres

Top speed

262 km/h


Chassis


Frame

tubular steel

Front suspension

independent, unequal-length wishbones, coil springs,

telescopic shock absorbers

Rear suspension

live axle, semi-elliptic springs,

large telescopic shock absorbers

Brakes

drums

Transmission

4-speed + reverse

Steering

worm and sector

Fuel tank

capacity 100 litres

Front tyres

6.50 x 16

Rear tyres

6.50 x 16


Bodywork

Type

coupé, cabriolet, two-seater

Length

-

Width

-

Height

-

Wheelbase

2800 mm

Front track

1455 mm

Rear track

1450 mm

Weight

1200 kg (dry)



Total

12


Ferrari 410 Superamerica Coupe Series III s/n 1015SA

Ferrari 410 Superamerica Coupé Pinin Farina Series III s/n 1015SA

Ferrari 410 Superamerica Series III s/n 1265SA

Ferrari 410 Superamerica Coupe SIII s/n 1285SA

6. - engine installed from 0495SA (410 SA S1)
.. - original engine from Griswold reunited with car

Ferrari 250 GT Pinin Farina Coupe s/n 1185GT - with later fitted bodywork

Ferrari 410 Superamerica Coupe Series III s/n 1305SA

Ferrari 410 Superamerica PF Coupe Series III s/n 1311SA

410 Superamerica Coupé Pinin Farina Series III s/n 1311SA

Ferrari 410 Superamerica s/n 1323SA

Ferrari 410 Superamerica Coupe SIII s/n 1387SA

 restamped 1355SA

Ferrari 410 Superamerica Coupe SIII s/n 1355SA

Chassis plate 1387SA
chassis still stamped 1355SA

8. - V8 engine installed

Ferrari 410 Superamerica PF Coupe SIII s/n 1423SA

Ferrari 410 Superamerica PF Coupe s/n 1449SA

Ferrari 410 SA s/n 1449SA

Ferrari 410 Superamerica Coupe s/n 1477SA

Ferrari 410 Superamerica Coupe s/n 1495SA
