Technical Specifications


Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder,

single overhead camshaft per cylinder bank

Bore and stroke

77 x 71 mm

Unitary and total displacement

330.62/3,967.44 cc

Compression ratio

8.8:1

Maximum power

300 bhp at 6,600 rpm

Fuel feed

3 Weber 40 DCZ 6 carbs

Ignition

single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

4-speed gearbox + overdrive + reverse,

conventional differential

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,650 / 1,397 / 1,389 mm

Kerb weight

1,380 kg

Fuel tank

90 litres

Top Speed

245km/h


Total

500 + 2 (prototype 1 & 2)
 Previous page
 Next page
Up

Ferrari 330 GT 2+2 s/n 6279GT

Ferrari 330 GT 2+2 s/n 6281GT

500 Superfast s/n 5981SA

Ferrari 330 GT 2+2 s/n 6283GT

Ferrari 500 Superfast s/n 5983SF

Ferrari 330 GT 2+2 s/n 6285GT

engine separated from car

Ferrari 330 GT s/n 6085 - 250 GTO "Favre" replica

Ferrari 330 GT 2+2 s/n 6287GT

engine separated from car

Ferrari 330 GT 2+2 s/n 6289GT

Ferrari 330 GT 2+2 s/n 6291GT

rebodied GTO style

Ferrari 330 GTO Replica s/n 6291GT

Ferrari 330 GT 2+2 s/n 6293GT

rebodied  '62 GTO style

Ferrari 250 LM Scaglietti Berlinetta s/n 5893

Ferrari 330 GT 2+2 s/n 6295GT

Ferrari 330 GT 2+2 s/n 6297GT

Ferrari 250 LM s/n 5897

Ferrari 330 GT 2+2 s/n 6299GT

Ferrari 330 GT 2+2 s/n 6301GT

rebodied 250 TR style


Ferrari 330 GT 2+2 s/n 6311GT

Ferrari 330 GT 2+2 s/n 6317GT

Ferrari 330 GT 2+2 s/n 6319GT

Ferrari 330 GT 2+2 s/n 6323GT

Ferrari 330 GT 2+2 s/n 6325GT

Ferrari 250 LM PF Coupe Speciale s/n 6025

Ferrari 330 GT 2+2 s/n 6327GT

Ferrari 330 GT 2+2 s/n 6329GT

250 GT/L, s/n 5729GT

Ferrari 330 GT 2+2 s/n 6331GT

Ferrari 330 GT 2+2 s/n 6333GT


rebodied GTO style
94/... - engine installed from 7245GT

250 LM s/n 6233

Ferrari 330 GT 2+2 s/n 6335GT

Ferrari 330 GT 2+2 s/n 6337GT

Ferrari 330 GT 2+2 s/n 6339GT

chassis and engine stamped 0592CM

500 Superfast Series I s/n 06039

Ferrari 330 GT 2+2 s/n 6341GT

Ferrari 330 GT 2+2 s/n 6343GT

Ferrari 500 Superfast, s/n 6043SF

Ferrari 330 GT 2+2 s/n 6347GT

Ferrari 250 GT Lusso s/n 5947

Ferrari 330 GT 2+2 s/n 6349GT

Ferrari 330 GT 2+2 s/n 6353GT

Ferrari 250 GT/L, s/n 5953GT

Ferrari 330 GT 2+2 s/n 6355GT

330 GT s/n 6155GT

Ferrari 330 GT 2+2 s/n 6359GT

Ferrari 330 GT 2+2 s/n 6361GT

engine separated from car

Ferrari 330 GT 2+2 s/n 6363GT

Ferrari 330 GT 2+2 s/n 6365GT

Ferrari 330 GT 2+2 s/n 6367GT

Ferrari 3330 GT 2+2 s/n 6369GT

engine installed in 6939GT

330 GT 2+2 Series I in pale yellow

Ferrari 330 GT 2+2 s/n 6371GT

Ferrari 330 GT 2+2 series I, s/n 6271

Ferrari 330 GT 2+2 s/n 6373GT

Ferrari 250 LM, s/n 6173

Ferrari 330 GT 2+2 s/n 6375GT

Ferrari 330 GT 2+2 s/n 6377GT

Ferrari 500 Superfast s/n 5977SF

Ferrari 330 GT 2+2 s/n 6379GT

Ferrari 330 GT 2+2 s/n 6381GT

500 Superfast s/n 5981SA

Ferrari 330 GT 2+2 s/n 6383GT

Ferrari 500 Superfast s/n 5983SF

Ferrari 330 GT 2+2 s/n 6385GT

Ferrari 330 GT s/n 6085 - 250 GTO "Favre" replica

Ferrari 330 GT 2+2 s/n 6387GT

Ferrari 330 GT 2+2 s/n 6389GT

Ferrari 330 GT 2+2 s/n 6391GT

engine separated from car

Ferrari 330 GTO Replica s/n 6291GT

Ferrari 330 GT 2+2 s/n 6393GT

Ferrari 330 GT 2+2 Series I #6393GT

Ferrari 330 GT 2+2 s/n 6395GT

212 barchetta Replica

Ferrari 330 GT 2+2 s/n 6397GT
