Technical Specifications


Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

206 kW (280 hp) at 7600 rpm

239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

two valves per cylinder

Fuel feed

three or six 40 Weber DCN/3 carburettors

Weber 6*40 DCN3

Weber 6*40 DCNG

Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs over telescopic shock absorbers,

anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4325 mm

Width

1725 mm

Height

1245 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

  1393 mm

Kerb weight

1100 kg


Performance


Top speed

258 km/h


Total

448
 Previous page
 Next page
Up

Ferrari 275 GTB s/n 08681

RHD
3 carb
steel

Ferrari 275 GTB s/n 08691

LHD
6 carb
alloy

Ferrari 275 GTB s/n 08697

LHD
3 carb
steel

Ferrari 275 GTB s/n 08699

RHD
3 carb
steel

Ferrari 275 GTB s/n 08699

Ferrari 275 GTB s/n 08707

LHD
3 carb
steel

Ferrari 275 GTB s/n 08717

LHD
3 carb
steel

Ferrari 275 GTB s/n 08729

LHD
3 carb
steel

Ferrari 275 GTB s/n 08737

LHD
3 carb
steel

Ferrari 330 GT 2+2 s/n 8637GT

Ferrari 275 GTB s/n 08743

LHD
6 carb
steel

Ferrari 275 GTB s/n 08747

RHD
3 (6) carb
steel

Ferrari 275 GTB, s/n 08647

Ferrari 275 GTB s/n 08749

LHD
6 carb
alloy

Ferrari 275 GTB/6C alloy s/n 08749

Ferrari 275 GTB s/n 08757

LHD
3 carb
steel

Ferrari 275 GTB s/n 08763

RHD
3 carb
steel

Ferrari 275 GTB/4 s/n 08769

LHD
steel

Prototipo

Ferrari 275 GTB s/n 08775

LHD
3 carb
steel

330 GT 2+2 s/n 8575GT

Ferrari 275 GTB s/n 08777

LHD
3 carb
steel

Ferrari 275 GTB s/n 08789

LHD
6 (3) carb
steel

Ferrari 275 GTB s/n 08795

LHD
3 carb
steel (alloy)

275 GTB longnose steel, s/n 08795

Ferrari 275 GTB s/n 08801

LHD
6 (3) carb
steel


Ferrari 275 GTB s/n 08813

LHD
3 carb
steel

250 GTE "Drogo" Conversion red/red s/n 3213GT/3881

Ferrari 275 GTB s/n 08835

LHD
3 carb
steel

Ferrari 275 GTB s/n 08841

LHD
3 carb
alloy

Ferrari 275 GTB s/n 08841

Ferrari 275 GTB s/n 08847

LHD
6 carb
steel

Ferrari 275 GTB s/n 08847

Ferrari 275 GTB s/n 08853

LHD
3 carb
steel

Ferrari 275 GTS s/n 08353

Ferrari 275 GTB s/n 08859

LHD
6 carb
alloy

Ferrari 275 GTB s/n 08863

LHD
3 carb
steel

Ferrari 275 GTB s/n 08869

LHD
3 carb
steel

Ferrari 275 GTB s/n 08877

LHD
3 carb
steel

275 GTB long nose, s/n 08877

Ferrari 275 GTB s/n 08891

LHD
6 carb
alloy

Ferrari 275 GTB 6C alloy s/n 08891

Ferrari 275 GTB s/n 08895

LHD
6 carb
steel

Ferrari 275 GTB s/n 08901

LHD
6 carb
alloy


Ferrari 275 GTB long nose Alloy s/n 08901


Ferrari 275 GTB s/n 08907

LHD
3 carb
steel

Ferrari 275 GTB s/n 08921

LHD
6 (3) carb
steel

Ferrari 275 GTB s/n 08931

LHD
3 carb
steel

Spyder conversion

Ferrari 330 GT s/n 8731GT

Ferrari 275 GTB s/n 08933

LHD
3 carb
steel

Ferrari 275 GTB s/n 08951

LHD
6 carb
steel

Ferrari 275 GTB s/n  8951 (Doyle/Girardo, UK)

Ferrari 275 GTB s/n 08955

LHD
3 carb
steel

250 GT Lusso & 275 GTB longnose, s/n 5853GT & 08955

Ferrari 275 GTB s/n 08961

RHD
3 carb
steel

Ferrari 275 GTB s/n 08973

LHD
3 carb
steel (alloy)

Ferrari 275 GTB s/n 08979

LHD
3 carb
steel

Last 275 GTB
