Technical Specifications


Engine

Type

128F and 128E/63

Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder, single overhead camshaft per

cylinder bank

Bore and stroke

73 x 58.8 mm

Unitary and total displacement

246.10/2,953.21 cc

Compression ratio

8.8:1

Maximum power

240 bhp at 7,000 rpm

Fuel feed

3 twin choke Weber 40 DCL6 carbs

Ignition

single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

4-speed gearbox + overdrive + reverse,

conventional differential


Chassis

Chassis type

508E

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,600 / 1,354 / 1,394 mm

Kerb weight

1,280 kg

Fuel tank

100 litres

Top Speed

230km/h


Total

302
 Previous page
 Next page
Up

Ferrari 250 GTE s/n 4341GT

Ferrari 400 SA LWB S.2 Cabriolet s/n 4241SA

Ferrari 250 GTE s/n 4343GT

250 GTE s/n 4243GT

Ferrari 250 GTE s/n 4345GT

Ferrari 250 GT PF Cabriolet S.II s/n 3645 GT - Lot 104

Ferrari 250 GTE s/n 4347GT

Ferrari 250 GTE s/n 4351GT

8. - rebodied as 250 TR Replica
8. - between San Diego and L.A. airport the car changed serial numbers to s/n 0666

Ferrari 400 Superamerica PF Coupe s/n 4251SA

Ferrari 250 GTE s/n 4353GT

Ferrari 250 GTE s/n 4355GT

Ferrari 250 GT PF S2 Cabriolet s/n 3655GT & 212 Touring Barchetta s/n 0158ED

Ferrari 250 GTE s/n 4357GT

Ferrari 250 GTE s/n 4361GT

Ferrari 250 GTE 2+2 S3 s/n 4161GT

Ferrari 250 GTE s/n 4367GT

Ferrari 250 GTE 2+2 S2 s/n 4067GT

Ferrari 250 GTE s/n 4369GT

90/... - engine installed in 6555GT

Ferrari 250 GTE s/n 4371GT

Ferrari 250 GTE s/n 4395GT

Ferrari 250 GTE s/n 4397GT

Ferrari 250 GTE s/n 4455GT

Ferrari 250 GT PF S2 Cabriolet s/n 3655GT & 212 Touring Barchetta s/n 0158ED

Ferrari 250 GTE s/n 4463GT

250 GTEs s/n 2433GT in the front and s/n 4163GT

Ferrari 250 GTE s/n 4473GT

250 GTE s/n 3837GT

Ferrari 250 GTE s/n 4475GT

Ferrari 250 GTE s/n 4477GT

.. - rebodied as TR Replica

Ferrari 250 GT/L s/n 4377GT

Ferrari 250 GTE s/n 4479GT

Ferrari 250 GTE s/n 4483GT

Ferrari 250 GT/Ls/n 4383GT

Ferrari 250 GTE s/n 4485GT

Ferrari 250 GT Lusso Berlinetta Speciale Pininfarina s/n 4385GT of  Lee Herrington

Ferrari 250 GTE s/n 4487GT

rebodied as a California Spyder

Ferrari 250 GTE s/n 4489GT

Ferrari 250 GT/L, s/n 4389GT

Ferrari 250 GTE s/n 4495GT

Ferrari 250 GTE s/n 4499GT

Ferrari 250 GTE s/n 4501GT

250 GTE 2+2 SII s/n 4101GT


Ferrari 250 GTE s/n 4505GT

Ferrari 250 GTE s/n 4507GT

Ferrari 250 GTE 2+2, s/n 4507GT

Ferrari 250 GTE s/n 4511GT

250 GT Lusso s/n 4411GT

Ferrari 250 GTE s/n 4515GT

250 GTE 2+2 s/n 4515GT

Ferrari 250 GTE s/n 4517GT

Ferrari 250 GTE s/n 4523GT

Ferrari 250 GTE s/n 4525GT

Ferrari 250 GT Lusso s/n 4425GT

Ferrari 250 GTE s/n 4529GT

250 GT Lusso s/n 4429GT, Mr. Schmitt

Ferrari 250 GTE s/n 4531GT

Ferrari 250 GTE s/n 4533GT

.. - rebodied as TR Replica

Ferrari 250 GTE s/n 4535GT

250 GTE 2+2 s/n 4135GT

Ferrari 250 GTE s/n 4541GT

Ferrari 400 SA LWB S.2 Cabriolet s/n 4241SA

Ferrari 250 GTE s/n 4543GT

250 GTE s/n 4243GT

Ferrari 250 GTE s/n 4545GT

Ferrari 250 GTE s/n 4547GT

engine installed in s/n 2379GT

Ferrari 250 GTE s/n 4551GT

Ferrari 400 Superamerica PF Coupe s/n 4251SA

Ferrari 250 GTE s/n 4553GT

..engine installed in 2779GT
.. - rebodied as 250 GT SWB Replica

Ferrari 330 LMB s/n 4453SA

Ferrari 250 GTE s/n 4557GT

Ferrari 250 GTE s/n 4559GT

Ferrari 250 GTE s/n 4565GT

Rebodied as GTO Replica

Ferrari 250 GTE s/n 4569GT

250 GTL s/n 4469GT

Ferrari 250 GTE s/n 4571GT
