Technical Specifications


Engine

Type

128F and 128E/63

Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder, single overhead camshaft per

cylinder bank

Bore and stroke

73 x 58.8 mm

Unitary and total displacement

246.10/2,953.21 cc

Compression ratio

8.8:1

Maximum power

240 bhp at 7,000 rpm

Fuel feed

3 twin choke Weber 40 DCL6 carbs

Ignition

single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

4-speed gearbox + overdrive + reverse,

conventional differential


Chassis

Chassis type

508E

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,600 / 1,354 / 1,394 mm

Kerb weight

1,280 kg

Fuel tank

100 litres

Top Speed

230km/h


Total

302
 Previous page
 Next page
Up

Ferrari 250 GTE s/n 3841GT

Ferrari 250 GTE s/n 3843GT

Ferrari 250 GTE s/n 3845GT

Ferrari 250 GT PF Cabriolet S.II s/n 3645 GT - Lot 104

Ferrari 250 GTE s/n 3853GT

Ferrari 250 GTE s/n 3855GT

rebodied as SWB Berlinetta

Ferrari 250 GTE s/n 3857GT

250 GTO s/n 3757GT

Ferrari 250 GTE s/n 3859GT

Ferrari 250 GTE s/n 3861GT

replica using engine 3661GT

Ferrari 250 GTE s/n 3865GT

Ferrari 250 GTE s/n 3871GT

250 GT SWB Nembo Spyder s/n 3771GT

Ferrari 250 GTE s/n 3873GT

rebodied GTO sytle

250 GTE s/n 3837GT

Ferrari 250 GTE s/n 3875GT

500 TRC "replica", #3675 GT

Ferrari 250 GTE s/n 3879GT

Ferrari 250 GTE 2+2 s/n 3679GT

Ferrari 250 GTE s/n 3881GT

rebodied as Drogo

Ferrari 250 GTE s/n 3883GT

rebodied as 250 TR

Ferrari 250 GTE s/n 3885GT

.. - engine installed in 3955GT

Ferrari 250 GT SWB California Spyder s/n 3185GT

Ferrari 250 GTE s/n 3887GT

rebodied as 500 TRC

Ferrari 250 GTE s/n 3889GT

Ferrari 250 GTE s/n 3891GT

Ferrari 250 GTE s/n 3893GT

250 GTE s/n 3593GT

Ferrari 250 GTE s/n 3895GT

Ferrari 250 GT SWB Berlinetta s/n 3695GT

Ferrari 250 GTE s/n 3897GT

Ferrari 250 GTE 2+2 s/n 3597GT

Ferrari 250 GTE s/n 3899GT

Ferrari 250 GTE 2+2 s/n 3799GT

Ferrari 250 GTE s/n 3901GT

Ferrari 250 GTE 2+2 SI s/n 3701GT



Ferrari 250 GTE s/n 3903GT

../... - engine installed in 1925GT
../... - engine installed stamped 3903 ...

Ferrari 250 GTE s/n 3905GT

08/... - engine 6559GT installed

Ferrari 250 GTE s/n 3907GT

Ferrari 250 GTE s/n 3913GT

rebodied California Spyder style

Ferrari 250 GTE s/n 3915GT

Ferrari 250 GTE s/n 3917GT

80's - engine in 1309GT

Ferrai 250 GTE 2+2 s/n 3817GT

Ferrari 250 GTE s/n 3919GT

.. - rebodied as GTO Spyder

Ferrari 250 GTE s/n 3219GT

Ferrari 250 GTE s/n 3921GT

Ferrari 400 Superamerica s/n 3621SA

Ferrari 250 GTE s/n 3925GT

250 GT Cabriolet Series II s/n 3525GT

Ferrari 250 GTE s/n 3927GT

../... engine installed in 1213GT

Ferrari 250 GTE s/n 3929GT

250 GT SWB s/n 3829GT

Ferrari 250 GTE s/n 3933GT

Ferrari 250 GTE s/n 3935GT

Ferrari 250 GTE s/n 3937GT

250 GTE s/n 3737GT  rebodied as SWB Berlinetta

Ferrari 250 GTE s/n 3939GT

250 GTE s/n 3839GT GTO Replica by Favre

Ferrari 250 GTE s/n 3941GT

Ferrari 250 GTE s/n 3945GT

Ferrari 250 GTE s/n 3947GT

Ferrari 250 GTE s/n 3951GT

Ferrari 250 GTE s/n 3953GT

Ferrari 250 GTE s/n 3955GT

.. - engine 3885 installed (250 GTE)

Ferrari 250 GT PF S2 Cabriolet s/n 3655GT & 212 Touring Barchetta s/n 0158ED

Ferrari 250 GTE s/n 3957GT

250 GTO s/n 3757GT

Ferrari 250 GTE s/n 3959GT

Ferrari 250 GTE s/n 3961GT

Ferrari 250 GTE s/n 3965GT

Ferrari 250 GTE s/n 3967GT

Ferrari 250 GT SWB California Spyder s/n 3867GT

Ferrari 250 GTE s/n 3969GT
