Technical Specifications



Engine

Rear longitudinal flat-12, lightened cylinder head

Timing gear

2 valves per cylinder, twin overhead camshafts per

cylinder bank

Bore and stroke

82x78 mm

Unitary and total displacement

411,84/4,942.10 cc

Compression ratio

10.3:1

Maximum power

455 bhp at 7,200 rpm

Transmission

Dry, twin 8.5" plate synterised clutch,

lightweight 5-speed gearbox + reverse,

gearbox oil cooler, 75% ZF limited-slip differential


Chassis

Tubular

Front suspension

Independent, double wishbones,

coil springs, Koni shock absorbers,

uniballs, 22 mm anti-roll bar

Rear suspension

Independent, double wishbones,

coil springs, Koni shock absorbers,

uniballs, 22 mm anti-roll bar

Wheelbase, front and rear track

5120/1563/1713 mm

Front tyres

10 x 15", Michelins

Rear tyres

13 x 15", Michelins

Fuel tank

Centrally-mounted safety tank, 120 litres

Top speed

308 km/h (with longest final drive ratio)


Total

25
 Previous page
 Next page
Up

Ferrari 512 BB LM s/n 26681

Ferrari 512 BB LM s/n 26683

Ferrari 512 BB/LM s/n 26683 - Paul Facella

Ferrari 512 BB LM s/n 26685

512 BBLM s/n 26685

Ferrari 512 BB LM s/n 27577

512 BBLM s/n 27577

Ferrari 512 BB LM s/n 27579

BB 512 LM80 s/n 27579

Ferrari 512 BB LM s/n 28601

Ferrari 512 BB/LM s/n 28601


Ferrari 512 BB LM s/n 29507

Ferrari 512 BB LM s/n 29509

Ferrari 512 BB LM s/n 29511

Ferrari 512 BB LM s/n 30559

Ferrari 512 BB LM s/n 31589

Ferrari BB 512 LM80 s/n 31589

Ferrari 512 BB LM s/n 32129

Ferrari 512 BB LM s/n 32131

Ferrari BB 512 LM80 s/n 32131

Ferrari 512 BB LM s/n 33647

Ferrari 512 BB LM s/n 34445

Ferrari 512 BB LM s/n 35523

Ferrari 512 BB LM s/n 34157

512 BBLM s/n 34157

Ferrari 512 BB LM s/n 35525

Ferrari 512 BB LM s/n 35529

512 BBLM s/n 35529

Ferrari 512 BB LM s/n 35527

512 BB/LM s/n 35527 & Porsche 908/3

Ferrari 512 BB LM s/n 38179

Ferrari 512 BB LM s/n 38181

BB 512 LM80 s/n 38181

Ferrari 512 BB LM s/n 38739

Ferrari 512 BB LM s/n 41263

512 BBLM s/n 41263

Ferrari 512 BB LM s/n 44023

BB 512 LM80 s/n 44023, serviced by Ferrari of Washington
