Technical Specifications



Engine

Rear longitudinal flat-12, lightened cylinder head

Timing gear

2 valves per cylinder, twin overhead camshafts per

cylinder bank

Bore and stroke

82x78 mm

Unitary and total displacement

411,84/4,942.10 cc

Compression ratio

10.3:1

Maximum power

455 bhp at 7,200 rpm

Transmission

Dry, twin 8.5" plate synterised clutch,

lightweight 5-speed gearbox + reverse,

gearbox oil cooler, 75% ZF limited-slip differential


Chassis

Tubular

Front suspension

Independent, double wishbones,

coil springs, Koni shock absorbers,

uniballs, 22 mm anti-roll bar

Rear suspension

Independent, double wishbones,

coil springs, Koni shock absorbers,

uniballs, 22 mm anti-roll bar

Wheelbase, front and rear track

5120/1563/1713 mm

Front tyres

10 x 15", Michelins

Rear tyres

13 x 15", Michelins

Fuel tank

Centrally-mounted safety tank, 120 litres

Top speed

308 km/h (with longest final drive ratio)
