Technical Specifications



Engine

213

Type

front, longitudinal 60° V12

Bore/stroke

77 x 58.8 mm

Unitary displacement

273.81 cc

Total displacement

3285.72 cc

Compression ratio

9.2 : 1

Maximum power

191 kW (260 hp) at 7000 rpm

 239 hp 7000 - 77x58 - 3286 - 6507


Valve actuation

single overhead camshaft per bank

 two valves per cylinder

Fuel feed

 three or six 40 Weber DCN/3 carburettors

 Weber 6*40 DCN3

 Weber 6*40 DCNG

 Weber 3*40 DCZ6

Ignition

single spark plug per cylinder, two coils

Lubrication

wet sump

Clutch

single-plate


Chassis

563

Frame

tubular steel

Front suspension

 independent, unequal-length wishbones,

 coil springs over telescopic shock absorbers,

 anti-roll bar

Rear suspension

independent, unequal-length wishbones,

 coil springs over telescopic shock absorbers,

 anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

worm and roller

Fuel tank

 capacity 94 litres

Tyres


Front

  195 or 205 x 14

Rear

  195 or 205 x 14


Borrani

RW 3847 - 6-1/2" x 14" 32

 RW 4039 7" x 14" 32

Compagnolo/starburst

6-1/2" x 14"


Bodywork

Type

two-seater berlinetta

Length

4350 mm

Width

1675 mm

Height

1250 mm

Wheelbase

2400 mm

Front track

1377 mm

Rear track

1393 mm

Kerb weight

1100 kg


Performance


Top speed

 242 km/h


Total

200



Previous page
Next page
Up

Ferrari 275 GTS s/n 07227

engine installed from 07529 (275 GTB)

Ferrari 275 GTS s/n 07235

Ferrari 275 GTS s/n 07235

Ferrari 275 GTS s/n 07257

Ferrari 275 GTS s/n 07265

Ferrari 275 GTS s/n 07275

Ferrari 330 GT 2+2 s/n 6775GT ? "DAH ZN 40H",

Ferrari 275 GTS s/n 07277

Ferrari 275 GTS s/n 07283

275 GTB s/n 6683

Ferrari 275 GTS s/n 07285

Ferrari 275 GTS s/n 07287

Ferrari 275 GTS sn 07287

Ferrari 275 GTS s/n 07289

Ferrari 275 GTS s/n 07293

RHD

Ferrari 275 GTS s/n 07297

Ferrari 275 GTS s/n 07301

275 GTB s/n 06901


Ferrari 275 GTS s/n 07305

Ferrari 275 GTS s/n 07309

Ferrari 250 GT/L s/n 5045GT

Ferrari 275 GTS s/n 07317

Ferrari 275 GTS 2+2 s/n 07325

Ferrari 275 GTS s/n 07331

275 GTS s/n 07331

Ferrari 275 GTS s/n 07337

Ferrari 275 GTS s/n 07345

Ferrari 275 GTS s/n 07345

Ferrari 275 GTS s/n 07359

330 GTS prototype

Ferrari 275 GTS s/n 07361

275 GTB/2 Longnose Spyder Conversion s/n 07061

Ferrari 275 GTS s/n 07367

Ferrari 275 GTS s/n 07367

Ferrari 275 GTS s/n 07379

Ferrari 275 GTS s/n 07383

Ferrari 275 GTS Pininfarina Spyder s/n 07383

Ferrari 275 GTS s/n 07389

Ferrari 275 GTS s/n 07395


Ferrari 275 GTS s/n 07403

275 GTS s/n 07203, displayed by Talacrest Ltd.

Ferrari 275 GTS s/n 07409

.. - engine installed in 06909 (275 GTS)

Ferrari 250 GT/L s/n 5045GT

Ferrari 275 GTS s/n 07419

Ferrari 275 GTS s/n 07423

Ferrari 250 GT/L s/n 5947 & 275 GTS s/n 07423

Ferrari 275 GTS s/n 07427

Ferrari 275 GTS s/n 07427

Ferrari 275 GTS s/n 07435

Ferrari 275 GTS s/n 07441

Ferrari 275 GTS s/n 07449

Ferrari 275 GTS s/n 07453

Ferrari 275 GTS s/n 07457

Ferrari 275 GTS s/n 07457 - Lot 106

Ferrari 275 GTS s/n 07465

Ferrari 275 GTS s/n 07469

Ferrari 275 GTB s/n 07269

Ferrari 275 GTS s/n 07475

Ferrari 275 GTS s/n 07479

Ferrari 275 GTS s/n 07487

3 posti

Ferrari 275 GTS s/n 07493

275 GTS s/n 7493

Ferrari 275 GTS s/n 07501


Ferrari 275 GTS s/n 07505

275 GTS s/n 07505

Ferrari 275 GTS s/n 07513

Ferrari 275 GTS s/n 07521

Ferrari 275 GTS s/n 07525

Ferrari 275 GTS s/n 07531

275 GTS s/n 07331

Ferrari 275 GTS s/n 07215
