Technical Specifications |
Engine |
Engine |
Front longitudinal 60° V12, |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| twin overhead camshafts per cylinder bank | |
Bore and stroke |
77 x 72 mm |
Unitary and total displacement |
335.27/4,023.32 cc |
Compression ratio |
9:1 |
Maximum power |
390 bhp at 7,400 rpm |
Transmission |
Multi-plate clutch, 4-speed gearbox + reverse, |
| ZF limited-slip differential |
Chassis |
Tubular |
Front suspension |
Independent, double wishbone, coil springs |
Rear suspension |
De Dion axle, coil springs |
Wheelbase, front and rear track |
2,350/1,296/1,310 mm |
Kerb weight |
880 kg |
Front tyres |
6.00-16 |
Rear tyres |
7.00-16 |
|
Total |
4 |
