Technical Specifications

Engine

Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

 Type

Construction Number 128LM

 Designer

Colombo

 Type

V-12

 Bore x Stroke

73.0 x 58.8

 Displacement

2953cc

 Compression Ratio

9.8:1

 Layout

Single overhead

 Camshaft Drive

Chain

 Cam Followers

Roller

 Valve Design

Inclined

 No. of Valves

2

 Values Springs

Hairpin - early TR's



Coil valve springs

 No. of Spark Plugs/Cylinder

1

 Ignition

2 Distributors

 No. of Carburetors

6

 Type of Carburetors

38 DCN

 Bhp @ rpm

280 Bhp @ 7200rpm

 Top speed

250 km/h


Drive Train

Clutch

Single dry plate


Transmission

No. of Gears

4-Speed & reverse

 Type

All synchro

 Location

With engine

 Axle Ration

3.55, 3.77, 4.00, 4.25, 4.59, 4.86:1


Chassis

Type

526B

 Chassis

Welded Tube

 Frame

Ladder

 Type Wheelbase

2350

 Track Front

1308

 Track Rear

1300

 Suspension Front

Independent Type Double wishbones



Springs Coils

 Suspension Rear

Rigid Axle - customer cars



De Doin - factory cars

 Springs

Coils

 Shocks

Houdaille

 Brakes

Drum


Wheels

Front

Borrani RW 3077

Rear

Borrani RW 3019


Tires

Front

5.50 x 16

 Rear

6.00 x 16


General
Body Designer

Body Builder

Scaglietti


Length cm
Overall
Width
Height

Curb Weight kg

900




Total

3

Ferrari 250 TR 58/59 s/n 0726TR

destroyed, chassis parts found

0726TR ... Ferrari 250 TR s/n 0726TR

Ferrari 250 Testa Rossa s/n 0728TR

Ferrari 296 Sport Scaglietti Spyder s/n 0746

modified to 250 TR58

Ferrari 250 TR/60 s/n 0746
