Technical Specifications |
Engine |
Engine |
Front longitudinal |
| in-line 4-cylinder, light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, twin overhead camshafts per bank |
Bore and stroke |
94 x 90 mm |
Unitary and total displacement |
624.58/2,498.32 cc |
Compression ratio |
9:1 |
Maximum power |
220 bhp at 7,000 rpm |
Transmission |
Multi-plate clutch, 4 speed-gearbox + reverse, |
| conventional differential |
Chassis |
Tubular longitudinals and cross members |
Front suspension |
Independent, double wishbones, |
| transverse lower leaf spring | |
Rear suspension |
De Dion axle, radius rods, transverse leaf spring |
Wheelbase, front and rear track |
2,250/1,278/1,284 mm |
Kerb weight |
730 kg |
Front tyres |
5.25-16 |
Rear tyres |
6.00-16 |
|
Vignale Spyder |
2 | 0304TF, 0306TF |
Vignale Berlinetta |
1 | 0302TF |
|
Total |
3 |
