Technical Specifications



Engine

Type

rear, transverse, 65° V6

Bore/stroke

86 x 57 mm

Unitary displacement

331.10 cc

Total displacement

1986.60 cc

Compression ratio

9 : 1

Maximum power

132 kW (180 hp) at 8000 rpm

Power per litre

91 hp/l

Maximum torque

-

Valve actuation

twin overhead camshaft per bank, two valves per

cylinder

Fuel feed

three Weber 40 DCN F/1 carburettors

Ignition

single spark plug per cylinder, single coil

Lubrication

wet sump

Clutch

single-plate


Chassis

Frame

tubular steel

Front suspension

independent, unequal-length wishbones,

coil springs, telescopic shock absorbers, anti-roll bar

Rear suspension

independent, unequal-length wishbones,

coil springs, telescopic shock absorbers, anti-roll bar

Brakes

discs

Transmission

5-speed + reverse

Steering

rack-and-pinion

Fuel tank

capacity 65 litres

Front tyres

185 VR 14

Rear tyres

185 VR 14


Bodywork


Type

two-seater berlinetta

Length

4150 mm

Width

1700 mm

Height

1115 mm

Wheelbase

2280 mm

Front track

1425 mm

Rear track

1400 mm

Weight

900 kg (dry)


Performance


Top speed

235 km/h

Acceleration 0-100 km/h

-

0-400 m

-

0-1000 m

27 sec.


Total

...
