Technical Specifications


Engine

Front longitudinal 60° V12,

light alloy cylinder block and head

Timing gear

2 valves per cylinder,

single overhead camshaft per cylinder bank

Bore and stroke

77 x 71 mm

Unitary and total displacement

330.62/3,967.44 cc

Compression ratio

8.8:1

Maximum power

300 bhp at 6,600 rpm

Fuel feed

3 Weber 40 DCZ 6 carbs

Ignition

single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

4-speed gearbox + overdrive + reverse,

conventional differential

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,650 / 1,397 / 1,389 mm

Kerb weight

1,380 kg

Fuel tank

90 litres

Top Speed

245km/h


Total

125
 Previous page
 Next page
Up

Ferrari 330 GT 2+2 s/n 7131GT

Ferrari 330 GT 2+2 s/n 7137GT

Ferrari 330 GT 2+2 s/n 7139GT

Ferrari 330 GT 2+2 s/n 7141GT

Ferrari 330 GT 2+2 s/n 7149GT

Ferrari 330 GT 2+2 s/n 7151GT

Ferrari 330 GT 2+2 s/n 7157GT

rebodied California Spyder style using engine 7157GT (new chassis)

Ferrari 330 GT 2+2 s/n 7161GT

275 GTB/2 Longnose Spyder Conversion s/n 07061

Ferrari 330 GT 2+2 s/n 7167GT

Ferrari 275 GTS s/n 06867

Ferrari 330 GT 2+2 s/n 7175GT

Ferrari 330 GT 2+2 s/n 7179GT

Ferrari 330 GT 2+2 s/n 7183GT

275 GTB s/n 6683

Ferrari 330 GT 2+2 s/n 7187GT

Ferrari 330 GT 2+2 s/n 7191GT

Ferrari 330 GT 2+2 s/n 7195GT

without engine

Ferrari 330 GT 2+2 s/n 7201GT

275 GTB s/n 06901


Ferrari 330 GT 2+2 s/n 7213GT

Ferrari 330 GT 2+2 s/n 7219GT

Ferrari 330 GT 2+2 s/n 7225GT

rebodied '62 GTO style

Ferrari 330 GTO Replica s/n 7225GT

Ferrari 330 GT 2+2 s/n 7229GT

Ferrari 330 GT 2+2 Series II s/n 7029GT

Ferrari 330 GT 2+2 s/n 7231GT

Ferrari 275 GTB s/n 06931

Ferrari 330 GT 2+2 s/n 7245GT

engine installed in 6333GT ('62 GTO replica)

275 GTB s/n 7147

Ferrari 330 GT 2+2 s/n 7251GT

Ferrari 330 GT 2+2 s/n 7253GT

Ferrari 330 GT 2+2 s/n 7255GT

Ferrari 330 GT 2+2 s/n 7259GT

Ferrari 330 GT 2+2 s/n 7267GT

Ferrari 275 GTS s/n 06867

Ferrari 330 GT 2+2 s/n 7273GT

Ferrari 330 GT 2+2 s/n 7279GT

Ferrari 330 GT 2+2 s/n 7281GT

engine installed in 6193GT

Ferrari 330 GT 2+2 s/n 7291GT


Ferrari 330 GT 2+2 s/n 7303GT

275 GTS s/n 07203, displayed by Talacrest Ltd.

Ferrari 330 GT 2+2 s/n 07313

Ferrari 330 GT 2+2 s/n 07321

Ferrari 330 GT 2+2 s/n 7323GT

Ferrari 330 GT 2+2 s/n 7329GT

Ferrari 330 GT 2+2 s/n 7335GT

Ferrari 275 GTS s/n 07235

Ferrari 330 GT 2+2 s/n 7339GT

Ferrari 275 GTB s/n 07239

Ferrari 330 GT 2+2 s/n 7343GT

Ferrari 330 GT 2+2 s/n 7349GT

Ferrari 330 GT 2+2 s/n 7353GT

2 HL conversion

Ferrari 330 GT 2+2 s/n 7355GT

Ferrari 330 GT 2+2 s/n 7363GT

Ferrari 330 GT 2+2 s/n 7369GT

Ferrari 275 GTB s/n 07269

Ferrari 330 GT 2+2 s/n 7375GT

Ferrari 330 GT 2+2 s/n 7377GT

Ferrari 330 GT 2+2 s/n 7387GT

Ferrari 330 GT 2+2 s/n 7393GT

Ferrari 330 GT 2+2 s/n 7399GT

Ferrari 330 GT 2+2 s/n 7405GT

Ferrari 330 GT 2+2 s/n 7265GT
