Technical Specifications


Engine

Front longitudinal 60° V12,

 light alloy cylinder block and head

Timing gear

2 valves per cylinder,

 single overhead camshaft per cylinder bank

Bore and stroke

77 x 71 mm

Unitary and total displacement

330.62/3,967.44 cc

Compression ratio

8.8:1

Maximum power

300 bhp at 6,600 rpm

Fuel feed

 3 Weber 40 DCZ 6 carbs

Ignition

 single spark plug per cyclinder, 2 coils

Transmission

Dry, single-plate clutch,

 4-speed gearbox + overdrive + reverse,

 conventional differential

Chassis

Elliptical section steel tubes

Front suspension

Independent, unequal-length wishbones, coil springs

Rear suspension

Live axle, semi-elliptic leaf springs

Wheelbase, front and rear track

2,650 / 1,397 / 1,389 mm

Kerb weight

1,380 kg

Fuel tank

90 litres

Top Speed

 245km/h


Total

455
Previous page
Next page
Up

Ferrari 330 GT 2+2 s/n 8289GT

Ferrari 330 GT 2+2 s/n 8291GT

Ferrari 330 GT 2+2 s/n 8293GT

Ferrari 330 GT 2+2 s/n 8295GT

Ferrari 275 GTB/6C, s/n 07995

Ferrari 330 GT 2+2 s/n 8301GT


Ferrari 330 GT 2+2 s/n 8307GT

Part of FOC Parking Area& 275 GTS s/n 08007

Ferrari 330 GT 2+2 s/n 8309GT

Ferrari 330 GT 2+2 s/n 8315GT

Ferrari 330 GT 2+2 s/n 8319GT

Ferrari 330 GT 2+2 s/n 8321GT

Ferrari 330 GT 2+2 s/n 8325GT

Ferrari 330 GT 2+2 s/n 8331GT

Ferrari 330 GT 2+2 s/n 8333GT

Ferrari 330 GT 2+2 s/n 8339GT

Ferrari 330 GT 2+2 s/n 8345GT

Ferrari 330 GT 2+2 s/n 8351GT

Ferrari 330 GT 2+2 s/n 8357GT

Ferrari 330 GT 2+2 s/n 8361GT

Ferrari 330 GT 2+2 s/n 8363GT

Ferrari 330 GT 2+2 s/n 8367GT

330 GT 2+2 series II, #8267

Ferrari 330 GT 2+2 s/n 8373GT

Ferrari 330 GT 2+2 s/n 8379GT

Ferrari 330 GT 2+2 s/n 8383GT

Ferrari 330 GT 2+2 s/n 8387GT

Ferrari 330 GT 2+2 s/n 8393GT

Ferrari 330 GT 2+2 s/n 8399GT

Ferrari 500 Superfast s/n 8299SF "WQG 888" (FL, USA)

Ferrari 330 GT 2+2 s/n 8401GT


Ferrari 330 GT 2+2 s/n 8405GT

Ferrari 275 GTS s/n 08005

Ferrari 330 GT 2+2 s/n 8409GT

Ferrari 330 GT 2+2 s/n 8411GT

Ferrari 275 GTB short nose front section s/n 7511

Ferrari 330 GT 2+2 s/n 8415GT

Ferrari 330 GT 2+2 s/n 8417GT

Ferrari 330 GT 2+2 s/n 8421GT

Ferrari 330 GT 2+2 s/n 8425GT

Ferrari 330 GT 2+2 s/n 8427GT

Ferrari 330 GT 2+2 s/n 8429GT

Ferrari 330 GT 2+2 s/n 8433GT

Ferrari 330 GT 2+2 s/n 8435GT

Ferrari 330 GT 2+2 s/n 8437GT

1964 Ferrari 275 GTB s/n 08337

Ferrari 330 GT 2+2 s/n 8441GT

rebodied SWB style

330 GT / SWB Replica s/n 8441GT

Ferrari 330 GT 2+2 s/n 8443GT

Ferrari 330 GT 2+2 s/n 8447GT

Ferrari 330 GT 2+2 s/n 8449GT

Ferrari 330 GT 2+2 s/n 8453GT

Ferrari 275 GTS s/n 08353

Ferrari 330 GT 2+2 s/n 8455GT

Ferrari 330 GT 2+2 s/n 8461GT

Ferrari 330 GT 2+2 s/n 8463GT

Ferrari 330 GT 2+2 s/n 8467GT

330 GT 2+2 series II, #8267

Ferrari 330 GT 2+2 s/n 8469GT

Ferrari 330 GT 2+2 s/n 8473GT

Ferrari 330 GT 2+2 s/n 8475GT
