Technical Specifications |
Engine |
Engine |
front, longitudinal 60° V6 |
Type |
Construction Number |
Designer |
Type |
V-6 |
Bore x Stroke |
85 x 71 mm |
Displacement |
2417.33 cc |
Compression Ratio |
9.8:1 |
Layout |
single overhead camshaft per bank |
Camshaft Drive |
Chain |
Cam Followers |
Roller |
Valve Design |
Inclined |
No. of Valves |
2 |
Values Springs |
Hairpin - early TR's |
|
Coil valve springs |
No. of Spark Plugs/Cylinder |
1 |
Ignition |
single coil |
No. of Carburetors |
3 |
Type of Carburetors |
42 DCN |
Lubrication |
wet sump |
Bhp @ rpm |
250 Bhp @ 7500rpm |
Top speed |
250 km/h |
|
Clutch |
Single dry plate |
|
No. of Gears |
4-Speed & reverse |
Type |
All synchro |
Location |
With engine |
Axle Ration |
3.55, 3.77, 4.00, 4.25, 4.59, 4.86:1 |
|
Type |
.... |
Chassis |
tubular steel |
Type Wheelbase |
2160 mm |
Track Front |
1245 mm |
Track Rear |
1205 mm |
Suspension Front |
independent, |
| unequal-length wishbones, | |
| coil springs, | |
| telescopic shock absorbers, | |
| anti-roll bar | |
Suspension Rear |
live axle, |
| radius arms, | |
| coil springs, | |
| telescopic shock absorbers |
|
Front |
Borrani RW .... |
Rear |
Borrani RW .... |
|
Front |
5.50 x 15 |
Rear |
6.00 x 15 |
|
Body Builder |
Scaglietti |
|
Curb Weight kg |
900 |
|
Total |
2 |
