Technical Specifications |
Engine |
Engine |
Front longitudinal 60° V12 |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| single overhead camshaft per cylinder bank | |
Bore and stroke |
55 x 52.5 mm |
Unitary and total displacement |
124.73 / 1,496.77 cc |
Compression ratio |
9.5:1 |
Maximum power |
118 bhp at 6,800 rpm |
Transmission |
Dry, single-plate clutch, |
| 5-speed gearbox + reverse |
Chassis |
Elliptical-section steel tubes |
Front suspension |
Independent, double wishbones, |
| lower transverse leaf spring | |
Rear suspension |
Live axle, semi-elliptic longitudinal leaf springs, |
| hydraulic dampers and anti-roll bar | |
Wheelbase, front and rear track |
2,420/1,255/1,200 mm |
Kerb weight |
750 kg |
Fuel tank |
75 litres |
|
| 01C, 02C |
Total |
2 |
