Technical Specifications |
Engine |
Engine |
Front longitudinal 60° V12, |
| light alloy cylinder block and head | |
Timing gear |
2 valves per cylinder, |
| single overhead camshaft per cylinder bank | |
Bore and stroke |
80 x 68 mm |
Unitary and total displacement |
341.80 / 4,101.66 cc |
Compression ratio |
8:1 |
Maximum power |
200 bhp at 5,000 rpm; 48 bhp/litre |
Transmission |
Dry, single-plate clutch, 4 speed-gearbox + reverse, |
| conventional differential | |
Chassis |
Elliptical section steel tubes |
Front suspension |
Independent, double wishbone, |
| single transverse leaf spring | |
Rear suspension |
Live axle, semi-elliptic longitudinal leaf springs |
Wheelbase, front and rear track |
2,650/1,325/1,320 mm |
Kerb weight |
1,200 kg |
Fuel tank |
105 litres |
Top speed |
186 km/h |
|
Test Sheet |
|
Ghia Coupe |
1 | 0130A |
Vignale Cabriolet |
1 | 0232AL |
Pinin Farina Berlinetta |
1 | 0236 |
Pinin Farina Cabriolet |
2 | 0234AL, 0248AL |
Pinin Farina Coupe |
3 | 0240AL, 0242AL, 0246AL |
Total |
8 |
