Mondial Pinin Farina Spyder |
Technical Specifications |
Engine |
Type - Construction Number |
110 Series I |
| 111 Series II | |
Designer |
Lampredi |
Type |
4-inline |
Bore x Stroke |
90.0 x 78.0 |
Displacement |
1984cc |
Compression Ratio |
9.2:1 |
Layout |
Double overhead |
Camshaft Drive |
Gears |
Cam Followers |
Roller tappet |
Valve Design |
Inclined |
No. of Valves |
2 Values |
Springs |
Hairpin |
No. of Spark Plugs/Cylinder |
2 |
Ignition |
2 Magnetos |
No. of Carburetors |
2 |
Type of Carburetors |
45 DCO/A3 |
| 40 DCO/A3 | |
Bhp @ rpm |
170 Bhp @ 7000rpm |
Top speed |
250 km/h |
Drive Train |
Clutch |
Double dry plate |
Transmission - No. of Gears |
5-Speed & reverse |
Transmission - Type |
Non synchro |
Transmission - Location |
With rear axle Axle |
Ration |
3.92, 4.12, 4.34, 5.06:1 |
Chassis |
Type |
510 |
Chassis |
Welded Tube |
Frame |
Ladder Type |
Wheelbase |
2250 |
Track Front |
1278 |
Track Rear |
1284 |
Suspension |
Front | Independent |
| Type | Double wishbones | |
| Springs | Transverse leaf - Series I |
| Coils - Series II |
Suspension |
Rear | De Doin |
| Springs | Transverse leaf |
Shocks |
Houdaille |
Brakes |
Drum |
Wheels |
Front | Borrani |
| Rear | Borrani | |
Tires |
Front | 5.50 x 16 |
| Rear | 6.00 x 16 |
General |
Body Designer |
Dino Ferrari | Farina |
Body Builder |
Scaglietti | Pinin Farina |
Length cm |
Overall |
| Width | |
| Height | |
Curb Weight kg |
900 |
|
Test Sheet |
0434 |
110 | 90x78 | 1985 | 160 hp 7000 |
Pinin Faraina Berlinetta |
2 | 0422MD, 0452MD |
Pinin Faraina Spyder |
12 | 0404MD renumbered 0414MD, 0408MD, 0410MD, 0414MD, |
| 0418MD, 0424MD, 0426MD, 0430MD, 0434MD, 0438MD, | |
| 0448MD, 0458MD |
Scaglietti Spyder Series I |
6 | 0406MD, 0454MD, 0464MD, 0468MD, 0474MD, 0506MD |
Scaglietti Spyder Series II 10 |
0446MD, 0512MD, 0528MD, 0534MD, 0536MD, 0556MD, |
| 0560MD, 0564MD, 0576MD, 0580MD |
Monoposto |
1 | 0574MD |
Engine |
1 | 0590MD |
|
|
renumbered 0564MD |
renumbered as 0556 |
or 735S |
renumbered from
0424MD |
