Technical Specifications |
Type - Construction Number |
340 |
Designer |
Lampredi |
Type |
V-12 |
Bore x Stroke |
80.0 x 68 |
Displacement |
4101cc |
Compression Ratio |
8.0:1 |
Layout |
Single overhead Camshaft |
Drive |
Chain |
Cam Followers |
Finger |
Valve Design |
Inclined |
No. of Valves |
2 |
Values Springs |
Hairpin |
No. of Spark Plugs/Cylinder |
1 |
Ignition |
2 Distributors |
No. of Carburetors |
3 |
Type of Carburetors |
40 DCF/3 |
Bhp @ rpm |
280 Bhp @ 6600rpm |
Top speed |
280 km/h |
|
Clutch |
Multi dry plate |
Transmission - No. of Gears |
5-Speed & reverse |
Transmission - Type |
Non synchro |
Transmission - Location |
With engine |
Axle Ration |
4.40, 4.90, 5.40:1 |
Chassis |
Type |
340 |
Chassis |
Welded Tube |
Frame |
Ladder Type |
Wheelbase |
2600 |
Track Front |
1278 |
Track Rear |
1250 |
Suspension |
Front | Independent |
| Type | Double wishbones |
| Springs Transverse leaf Suspension |
| Rear | Rigid axle |
| Springs Longitudinal semi elliptic leaf springs | |
Shocks |
Houdaille |
Brakes |
Drum |
Whells |
Front | Borrani |
| Rear | Borrani | |
Tires |
Front | 6.00 x 16 |
| Rear | 6.50 x 16 |
General |
Body Designer |
Body builder |
Vignale |
Length Overall |
|
Width |
|
Height |
|
Curb Weight |
kg 950 |
|
