Technical Specifications |
Engine |
Type - Construction Number |
250 |
Designer |
Colombo |
Type |
V-12 |
Bore x Stroke |
73.0 x 58.8 |
Displacement |
2953cc |
Compression Ratio |
9.0:1 |
Layout |
Single overhead Camshaft |
Drive |
Chain |
Cam Followers |
Finger |
Valve Design |
Inclined |
No. of Valves |
2 |
Values Springs |
Hairpin |
No. of Spark Plugs/Cylinder |
1 |
Ignition |
2 Distributors |
No. of Carburetors |
3 |
Type of Carburetors |
36 IF 4/c or 36 DCZ or 36 DCF or 40 IF 4/c |
Bhp @ rpm |
240 Bhp @ 7200rpm |
Drive Train |
Clutch |
Multiple disc |
Transmission - No. of Gears |
4-Speed & reverse |
Transmission - Type |
All synchro |
Transmission - Location |
With engine |
Axle Ration |
3.636, 4.000 4.250 or 4.444:1 |
Chassis |
Type |
250MM53 |
Chassis |
Welded Tube |
Frame |
Ladder Type |
Wheelbase |
2400 |
Track Front |
1325 |
Track Rear |
1320 |
Suspension |
Front | Independent |
| Type | Unequal length A arms | |
| Springs | Transverse leaf | |
Suspension |
Rear | Rigid axle |
| Springs | Semi elliptic |
Shocks |
Houdaille |
Brakes |
Drum |
Wheels |
Front | Borrani |
| Rear | Borrani | |
Tires |
Front | 5.50 x 16 or 6.40 x 15 |
| Rear | 6.00 x 16 or 6.40 x 15 |
General |
Body Designer |
Body Builder |
Pinin Farina | Vignale |
Length cm |
Overall |
| Width | |
| Height | |
Curb Weight kg |
|
Test Sheet |
| 250 | 73.0 x 58.8 | 2953 | 240 hp @ 7200 |
|
Pinin Farin Berlinetta |
18 | 0250MM, 0252MM, 0254MM, 0256MM, 0258MM, 0270MM, |
| 0276MM, 0292MM, 0298MM, 0310MM, 0312MM, 0316MM, | |
| 0338MM, 0340MM, 0344MM, 0352MM, 0354MM, 0356MM |
Vignale Spyder Series I |
2 | 0230MM**, 0260MM |
Vignale Spyder Series II |
low door line |
4 | 0274MM, 0282MM*, 0288MM**, 0296MM** |
Vignale Spyder Series III |
6 | 0326MM**, 0330MM**, 0332MM, 0336MM, 0348MM, 0390MM |
Vignale Berlinetta |
1 | 0334MM |
|
|
