Technical Specifications |
Engine |
Type |
front, longitudinal 60° V12 |
Bore/stroke |
81 x 71 mm |
Unitary displacement |
365.86 cc |
Total displacement |
4390.35 cc |
Compression ratio |
8.8 : 1 |
Maximum power |
235 kW (320 hp) at 6600 rpm |
Power per litre |
73 hp/l |
Maximum torque |
- |
Valve actuation |
single overhead camshaft per bank, two valves per cylinder |
Fuel feed |
three twin-choke Weber 40 DFI/5 carburettors |
Ignition |
single spark plug per cylinder, two coils |
Lubrication |
wet sump |
Clutch |
single-plate |
|
Type |
571 (Prototype) |
| 598 remaining 13 |
Frame |
tubular steel |
Front suspension |
independent, |
| unequal-length wishbones, | |
| coil springs, | |
| telescopic shock absorbers, | |
| anti-roll bar | |
Rear suspension |
live axle, |
| radius arms, | |
| semi-elliptic springs, | |
| coil springs over telescopic shock absorbers | |
Brakes |
discs |
Transmission |
5-speed + reverse |
Steering |
servo-assisted recirculating ball |
Fuel tank |
capacity 100 litres |
Front tyres |
205 x 15 |
Rear tyres |
205 x 15 |
|
Type |
two-seater spider |
Length |
4900 mm |
Width |
1780 mm |
Height |
1330 mm |
Wheelbase |
2650 mm |
Front track |
1405 mm |
Rear track |
1397 mm |
Weight |
1320 kg (dry) |
|
Top speed |
245 km/h |
Acceleration |
0-100 km/h |
|
|
